| Nombor Bahagian | AM-640480G4TNQW-TA0H |
| Jenama | AMPIRE |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 250:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | AMPIRE |
| nama model | AM-640480G4TNQW-TA0H |
| saiz skrin | 5.7 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 640(RGB)×480 (VGA) 141PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 115.2 × 86.4 (H×V) |
| garis besar (mm) | 127 × 98.43 × 9.1 (H×V×D) |
| kawasan bezel (mm) | 118.0 × 89.2 (H×V) |
| rawatan | - |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 250 : 1 (Typ.) (TM) |
| sudut pandangan | 70/70/50/50 (Typ.)(CR≥10) |
| tindak balas | 50 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | 12 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K 50% NTSC |
| lampu latar | WLED , 20K hours , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | 4-wire Resistive Touch |
| jenis isyarat | LVDS (1 ch, 6-bit) , Connector 20 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
