| Nombor Bahagian | AM-1280800P4TZQW-T01H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | AMPIRE |
| model | AM-1280800P4TZQW-T01H |
| saiz pepenjuru | 7.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 217PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 149.76(H)×93.6(V) mm |
| garis besar malap. | 162.3(H)×107.9(V) ×11.76(D) mm |
| kawasan bezel | 152.76(H)×96.6(V) mm |
| rawatan | - |
| kecerahan | 1275 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | SFT, Normally Black, Transmissive |
| warna sokongan | 16.7M 50% NTSC |
| sumber cahaya | WLED [5S4P] , 50K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial Outdoor High Brightness |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
