| Nombor Bahagian | AM-1024768V1TZQW-A0H |
| Jenama | AMPIRE |
| Saiz | 8.4 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| saiz pepenjuru | 8.4 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 152PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 170.8(H)×128.1(V) mm |
| garis besar malap. | 203(H)×145.5(V) ×8(D) mm |
| kawasan bezel | 174.15(H)×131.2(V) mm |
| rawatan | - |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M |
| sumber cahaya | WLED [6S6P] , 50K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC21-11 | NLT | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
