| Nombor Bahagian | AM-1024600L2HMQW-T01H |
| Jenama | AMPIRE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM-1024600L2HMQW-T01H |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 222.72(H)×125.28(V) mm |
| garis besar malap. | 235(H)×145.8(V) ×9.8(D) mm |
| kawasan bezel | 225.92(H)×128.48(V) mm |
| rawatan | - |
| kecerahan | 800 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 4/12 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K 47% NTSC |
| sumber cahaya | WLED [6S6P] , 50K hours , With LED Driver |
| berat badan | TBD |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | 4-wire Resistive Touch |
| jenis antara muka | LVDS (1 ch, 6-bit) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
