| Nombor Bahagian | AM-1024600ITZQW-00H |
| Jenama | AMPIRE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AMPIRE |
| model panel | AM-1024600ITZQW-00H |
| saiz panel | 10.1" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×600, WSVGA, 117PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 222.72(W)×125.28(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 234.9(W)×143(H) ×4.9(D) mm |
| permukaan | Antiglare, Hard coating |
| kecerahan | 550 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 12/28 (Typ.)(Tr/Td) |
| warna paparan | 262K/16.7M 70% NTSC |
| jenis lampu | WLED , 50K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| voltan masukan | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
