| Nombor Bahagian | AM-1024600DTZQW-A6H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1024×600 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | AMPIRE |
| nama model | AM-1024600DTZQW-A6H |
| saiz skrin | 7.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1024(RGB)×600 (WSVGA) 170PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 154.221 × 85.92 (H×V) |
| garis besar (mm) | 164.9 × 100 (H×V×D) |
| kawasan bezel (mm) | 158 × 89.7 (H×V) |
| rawatan | Antiglare |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 13/15 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | WLED , 50K hours , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial Outdoor High Brightness |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (1 ch, 8-bit) , 20 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
