| Nombor Bahagian | AG-12864CYIQY-14H-A(R) |
| Jenama | AMPIRE |
| Saiz | 2.7 |
| Permohonan | IA |
| Resolusi | 128×64 |
| Komposisi | LCM |
| Kecerahan | 7 |
| CR | 4:1 |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antara muka | CPU |
| jenama panel | AMPIRE |
| model panel | AG-12864CYIQY-14H-A(R) |
| jenis panel | STN-LCD , LCM |
| saiz panel | 2.7 inch |
| resolusi | 128×64 |
| mod paparan | STN, Yellow/Green (Positive), Transflective |
| kawasan aktif | 56.28×38.36 mm |
| garis besar | 78×70×13 mm |
| permukaan | |
| kecerahan | 7 cd/m² (Typ.) |
| nisbah kontras | 4:1 (Typ.)(Transmissive) |
| warna paparan | Monochrome |
| masa tindak balas | 140/240 (Typ.)(Tr/Td) |
| sudut pandangan | 35/35/35/40 (Typ.)(CR≥2)(L/R/U/D) |
| kekerapan | 70Hz |
| jenis lampu | 2S5PYG-LEDWithout Driver |
| antara muka isyarat | 8-bit parallel, 20 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | IA |
| A027DN03 V8 | AUO | 2.7 | 320×240 |
| A027DTN01.2 | AUO | 2.7 | 320×240 |
| AG-12864CYIQY-14H-A(R) | AMPIRE | 2.7 | 128×64 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| OEL9M0065-G-E | Other | 2.7 | 256×64 |
| OEL9M0065-Y-E | Other | 2.7 | 256×64 |
| OEL9M5001-G-E | Other | 2.7 | 128×64 |
| OEL9M5001-R-E | Other | 2.7 | 128×64 |
| OEL9M5001-W-E | Other | 2.7 | 128×64 |
| TM027CDH02 | Tianma | 2.7 | 320×240 |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| G104VN01 V0 | AUO | 10.4 | 640×480 |
| LT121AC62000 | TOSHIBA | 12.1 | 1024×768 |
| LTM12C275A | TOSHIBA | 12.1 | 800×600 |
| MXS121022010 | SANYO | 12.1 | 800×600 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| OEL9M0065-W-E | Other | 2.7 | 256×64 |
| SX19V001-ZZB | KOE | 7.5 | 640×480 |
| TCG057QVLCA-G00 | Kyocera | 5.7 | 320×240 |
