| Nombor Bahagian | ZJ070IA-17D |
| Jenama | Innolux |
| Saiz | 7.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 10S2P |
| Antara muka | MIPI |
| jenama panel | Innolux |
| saiz panel | 7.0" |
| resolusi | 800(RGB)×1280, WXGA, 215PPI |
| kawasan paparan | 94.2(W)×150.72(H) mm |
| saiz garis besar | 103.5(W)×162.22(H) ×4.51(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M |
| kekerapan | 60Hz |
| berat panel | 87.0g (Max.) |
| antara muka isyarat | MIPI (4 data lanes) , 31 pins Connector |
| voltan masukan | 1.8/3.3V (Typ.)(VDD/VDDIO) |
| persekitaran | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
| model panel | ZJ070IA-17D |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 97.35(W)×153.82(H) mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | AAS, Normally Black, Transmissive |
| masa tindak balas | 11/9 (Typ.)(Tr/Td) |
| jenis lampu | 10S2P WLED , 15K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Pad & Tablet |
