| Nombor Bahagian | WG19232B-TFH-T#T |
| Jenama | Winstar |
| Saiz | 3.2 |
| Permohonan | Industrial Instrumen |
| Resolusi | 192×32 |
| Komposisi | FSTN-LCD, LCM |
| Kecerahan | |
| CR | 5:1 |
| Warna | Monochrome |
| Lampu latar | WLED |
| Antara muka | 8-bit |
| jenama | Winstar |
| model | WG19232B-TFH-T#T |
| saiz pepenjuru | 3.2 inch |
| menaip | FSTN-LCD, LCM |
| format piksel | 192×32 60PPI |
| konfigurasi | Rectangle |
| kawasan aktif | 80.6(H)×15.96(V) mm |
| garis besar malap. | 116(H)×37(V) ×13.9(D) mm |
| kawasan bezel | 85.0(H)×18.6(V) mm |
| rawatan | - |
| kecerahan | - |
| nisbah kontras | 5:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 150/150 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/30/60 (Typ.)(CR≥2) |
| mod operasi | STN, Black/White (Positive), Transflective |
| warna sokongan | Monochrome |
| sumber cahaya | WLED , 30K hours , W/O Driver |
| berat badan | - |
| direka untuk | Industrial Instruments & Meters |
| kadar bingkai | - |
| panel sentuh | Without |
| jenis antara muka | 8-bit 6800/8080 parallel , 16 pins Pad |
| bekalan kuasa | 5.0V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
