| Nombor Bahagian | WG12232E-TGH-V#A |
| Jenama | Winstar |
| Saiz | 2.2 |
| Permohonan | Industrial Instrumen |
| Resolusi | 122×32 |
| Komposisi | STN-LCD, LCM |
| Kecerahan | |
| CR | 3:1 |
| Warna | Monochrome |
| Lampu latar | WLED |
| Antara muka | 8-bit |
| jenama panel | Winstar |
| model panel | WG12232E-TGH-V#A |
| saiz panel | 2.2" |
| jenis panel | STN-LCD, LCM |
| resolusi | 122×32, 57PPI |
| format piksel | Rectangle |
| kawasan paparan | 53.64(W)×15.64(H) mm |
| pembukaan bezel | 60.0(W)×18.0(H) mm |
| saiz garis besar | 80(W)×36(H) ×13.7(D) mm |
| permukaan | - |
| kecerahan | - |
| nisbah kontras | 3:1 (Typ.) (TM) |
| sudut pandangan | 30/30/20/40 (Max.)(CR≥2) |
| mod paparan | STN, Blue/Grey (Positive), Transflective |
| pandangan terbaik pada | 6 o'clock |
| masa tindak balas | 150/150 (Typ.)(Tr/Td) |
| warna paparan | Monochrome |
| jenis lampu | WLED , 50K hours , Without Driver |
| kekerapan | - |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Industrial Instruments & Meters |
| antara muka isyarat | 8-bit 6800/8080 parallel , 20 pins Pad |
| voltan masukan | 3.0V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
