| Nombor Bahagian | WEO012832AS |
| Jenama | Winstar |
| Saiz | 2.2 |
| Permohonan | Handheld & PDA I |
| Resolusi | 128×32 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Blue) |
| Lampu latar | self |
| Antara muka | 8-bit |
| pengilang | Winstar |
| nama model | WEO012832AS |
| saiz skrin | 2.2 inch |
| jenis skrin | OLED , PM-OLED |
| nombor piksel | 128×32 59PPI |
| susunan | Rectangle |
| kawasan aktif (mm) | 55.018 × 13.098 (H×V) |
| garis besar (mm) | 62 × 24 × 2.35 (H×V×D) |
| kawasan bezel (mm) | 57.02 × 15.1 (H×V) |
| rawatan | - |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | Mono(Blue) |
| lampu latar | self |
| jisim | - |
| digunakan untuk | Handheld & PDA Instruments & Meters |
| kadar segar semula | - |
| skrin sentuh | Without |
| senarai ic pemandu | Built-in COG SSD1305Z |
| jenis isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| bekalan voltan | 3.0V (Typ.) |
