| Nombor Bahagian | WEH002002BW |
| Jenama | Winstar |
| Saiz | 5.7 |
| Permohonan | Instruments & Me |
| Resolusi | 20×23 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | CPU/SPI |
| jenama panel | Winstar |
| model panel | WEH002002BW |
| saiz panel | 5.7" |
| jenis panel | PM-OLED, OLED |
| format paparan | 20 characters × 2 lines, 3PPI |
| format fon | 5×8 dots |
| saiz watak | 6×9.66(W×H) mm |
| nada watak | 7.32×10.98(W×H) mm |
| kawasan paparan | 145.08(W)×20.64(H) mm |
| pembukaan bezel | 149.0(W)×23.0(H) mm |
| saiz garis besar | 180(W)×40(H) ×9.3(D) mm |
| permukaan | - |
| sudut pandangan | - |
| mod paparan | - |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | - |
| warna paparan | Mono(White) |
| jenis lampu | self |
| kekerapan | - |
| skrin sentuh | Without |
| ic pemandu | COBBuilt-in WS0010 |
| berat panel | - |
| permohonan | Instruments & Meters |
| antara muka isyarat | CPU/SPI , 16 pins Pad |
| voltan masukan | 5.0V (Typ.) |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| CLAA057VA01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| KCG057QV1DB-G77 | Kyocera | 5.7 | 320×240 |
| KCS057QV1AJ-G32 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LM32004 | SHARP | 5.7 | 320×240 |
| SH320240C | Other | 5.7 | 320×240 |
