| Nombor Bahagian | WEG007616AB |
| Jenama | Winstar |
| Saiz | 1.7 |
| Permohonan | Instruments & Me |
| Resolusi | 76×16 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Blue) |
| Lampu latar | self |
| Antara muka | CPU/SPI |
| jenama | Winstar |
| model | WEG007616AB |
| saiz pepenjuru | 1.7 inch |
| menaip | PM-OLED, OLED |
| format piksel | 76×16 45PPI |
| konfigurasi | Rectangle |
| kawasan aktif | 41.7(H)×11.1(V) mm |
| garis besar malap. | 55.7(H)×32(V) ×11(D) mm |
| kawasan bezel | 46(H)×14.5(V) mm |
| rawatan | - |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | - |
| mod operasi | - |
| warna sokongan | Mono(Blue) |
| sumber cahaya | self |
| berat badan | - |
| direka untuk | Instruments & Meters |
| kadar bingkai | - |
| panel sentuh | Without |
| perincian d-ic | COB Built-in WS0010 |
| jenis antara muka | CPU/SPI , 15 pins Pad |
| bekalan kuasa | 5.0V (Typ.) |
