| Nombor Bahagian | WEA012864DLPP3N00003 |
| Jenama | Winstar |
| Saiz | 0.96 |
| Permohonan | Instruments & Meters |
| Resolusi | 128×64 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antara muka | 4-wire |
| pengilang | Winstar |
| saiz skrin | 0.96 inch |
| nombor piksel | 128×64 149PPI |
| kawasan aktif (mm) | 21.74 × 10.86 (H×V) |
| kawasan bezel (mm) | 23.94 × 12.06 (H×V) |
| sudut pandangan | - |
| pandangan yang baik di | Symmetry |
| kedalaman warna | Mono(Yellow) |
| jisim | - |
| kadar segar semula | - |
| senarai ic pemandu | Built-in COG SSD1306BZ |
| jenis isyarat | 4-wire SPI, I²C , 8 pins PIN |
| bekalan voltan | 3.3/5.0/7.5V (Typ.) |
| maks. penilaian | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| nama model | WEA012864DLPP3N00003 |
| jenis skrin | OLED , PM-OLED |
| susunan | Rectangle |
| garis besar (mm) | 38 × 28.5 × 4.37 (H×V×D) |
| rawatan | - |
| tindak balas | - |
| mod kerja | - |
| lampu latar | self |
| digunakan untuk | Instruments & Meters |
| skrin sentuh | Without |
