| Nombor Bahagian | VVX09F035M20 |
| Jenama | Panasonic |
| Saiz | 8.9 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | Panasonic |
| model panel | VVX09F035M20 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.9 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | IPS-Pro, Normally Black, Transmissive |
| kawasan aktif | 191.52×119.7 mm |
| garis besar | 203.5×135.9×4.8 mm |
| permukaan | Hard coating |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Dithering), CIE193150% |
| masa tindak balas | 30 (Max.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥80)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S5PWLEDWithout Driver |
| antara muka isyarat | eDP (2 Lanes), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
