| Nombor Bahagian | LD089WU1-SM01 |
| Jenama | LG Display |
| Saiz | 8.9 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 360 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | LG Display |
| model panel | LD089WU1-SM01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.9 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 191.52×119.7 mm |
| garis besar | 203.4×135.85×5.25 mm |
| permukaan | Hard coating |
| kecerahan | 360 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S5PWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 45 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
