| Nombor Bahagian | V850DK1-KD1 Rev.B1 |
| Jenama | Innolux |
| Saiz | 85 |
| Permohonan | LCTV |
| Resolusi | 3840×2160 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 3000:1 |
| Warna | 1.07B |
| Lampu latar | WLED |
| Antara muka | V-by-One |
| jenama panel | INNOLUX |
| model panel | V850DK1-KD1 Rev.B1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 85 inch |
| resolusi | 3840(RGB)×2160 , UHD |
| mod paparan | Super MVA, Normally Black, Transmissive |
| kawasan aktif | 1872×1053 mm |
| garis besar | 1902.6×1083.6×53.8 mm |
| permukaan | Antiglare (Haze 0.5%) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 3000:1 (Typ.) |
| warna paparan | 1.07B (8-bit + Hi-FRC), CIE1931100% |
| masa tindak balas | 6.5 (Typ.)(G to G) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| kekerapan | 120Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | V-by-One 16 lane, 97 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
