Innolux V546HK3-LS5 Rev.C7 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


V546HK3-LS5 Rev.C7

V546HK3-LS5 Rev.C7
V546HK3-LS5 Rev.C7 thumb
Jenama
Innolux
Saiz
55
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
5000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
8580
Spesifikasi

Nombor Bahagian V546HK3-LS5 Rev.C7
JenamaInnolux
Saiz55
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR5000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV546HK3-LS5 Rev.C7
jenis panel a-Si TFT-LCD , LCM
saiz panel55 inch
resolusi1920(RGB)×1080 , FHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif1209.6×680.4 mm
garis besar1237.4×711.3 mm
permukaanAntiglare (Haze 11%), Hard coating (3H)
kecerahan400 cd/m² (Typ.)
nisbah kontras5000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan120Hz (60Hz Input)
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 61 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
