LG Display LC420DUK-SGK2 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LC420DUK-SGK2

LC420DUK-SGK2
LC420DUK-SGK2
LC420DUK-SGK2 thumb LC420DUK-SGK2 thumb
Jenama
LG Display
Saiz
42
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
1400:1
Warna
16.7M/1.06B
Lampu latar
No B/L
Antara muka
LVDS
In Stock
50
Spesifikasi

Nombor Bahagian LC420DUK-SGK2
JenamaLG Display
Saiz42
PermohonanLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR1400:1
Warna16.7M/1.06B
Lampu latarNo B/L
Antara mukaLVDS
jenama panelLG Display
model panelLC420DUK-SGK2
jenis panel a-Si TFT-LCD , CELL
saiz panel42 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif927.936×521.964 mm
garis besar943.6×538.3 mm
permukaanAntiglare (Haze 1%), Hard coating (2H)
kedalaman kaca0.50+0.50 mm
ketransmisian6.58% (Typ.)(with Polarizer)
nisbah kontras1400:1 (Typ.)
warna paparan16.7M/1.06B (8-bit / 8-bit + Dithering)
masa tindak balas5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan120Hz
antara muka isyaratLVDS (4 ch, 8/10-bit), 92 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LC420DUE-FGA6 LG Display 42 1920×1080
LC420DUE-SFR1 LG Display 42 1920×1080
LC420DUE-SFR2 LG Display 42 1920×1080
LC420DUE-SFR3 LG Display 42 1920×1080
LC420DUE-SFU2 LG Display 42 1920×1080
LC420DUF-VGF1 LG Display 42 1920×1080
LC420DUH-FGA1 LG Display 42 1920×1080
LC420DUH-FGP1 LG Display 42 1920×1080
LC420DUJ-SGE3 LG Display 42 1920×1080
LC420DUK-SGK2 LG Display 42 1920×1080
