| Nombor Bahagian | V500HJ1-PE8 Rev.C3 |
| Jenama | Chimei Innolux |
| Saiz | 50 |
| Permohonan | Transparent Display |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | Chimei Innolux |
| saiz panel | 50" |
| resolusi | 1920(RGB)×1080, FHD, 44PPI |
| kawasan paparan | 1095.84(W)×616.41(H) mm |
| saiz garis besar | 1112.32(W)×631.61(H) ×1.31(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥20) |
| pandangan terbaik pada | Symmetry |
| kedalaman kaca | 0.50+0.50 mm |
| warna paparan | 16.7M 70% NTSC |
| kekerapan | 60Hz |
| ic pemandu | COF Built-in 6 source + 4 gate chips |
| berat panel | 1.99±0.19Kgs |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | V500HJ1-PE8 Rev.C3 |
| jenis panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| nisbah kontras | 5000:1 (Typ.) (TM) |
| mod paparan | Super MVA, Normally Black, Transmissive |
| masa tindak balas | 8.5 (Typ.)(G to G) |
| ketransmisian | 5.6% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| skrin sentuh | Without |
| permohonan | Transparent Display |
| LC500DUE-SFR1 | LG Display | 50 | 1920×1080 |
| LC500EUD-FFF3 | LG Display | 50 | 1920×1080 |
| T500HVN04.1 CELL | AUO | 50 | 1920×1080 |
| T500HVN04.5 CELL | AUO | 50 | 1920×1080 |
| T500QVN01.1 CELL | AUO | 50 | 3840×2160 |
| V500HJ1-L01 | Innolux | 50 | 1920×1080 |
| V500HJ1-LE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE8 | Innolux | 50 | 1920×1080 |
| V500HK1-LS6 Rev.C7 | Innolux | 50 | 1920×1080 |
