AUO T500HVN04.1 CELL lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T500HVN04.1 CELL

T500HVN04.1 CELL
T500HVN04.1 CELL
T500HVN04.1 CELL
T500HVN04.1 CELL thumb T500HVN04.1 CELL thumb T500HVN04.1 CELL thumb
Jenama
AUO
Saiz
50
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
3000:1
Warna
16.7M
Lampu latar
No B/L
Antara muka
LVDS
In Stock
16050
Spesifikasi

Nombor Bahagian T500HVN04.1 CELL
JenamaAUO
Saiz50
PermohonanLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR3000:1
Warna16.7M
Lampu latarNo B/L
Antara mukaLVDS
jenama panelAUO
model panelT500HVN04.1 CELL
jenis panel a-Si TFT-LCD , CELL
saiz panel50 inch
resolusi1920(RGB)×1080 , FHD
mod paparanAMVA, Normally Black, Transmissive
kawasan aktif1095.84×616.41 mm
garis besar1105.8×665 mm
permukaanAntiglare, Hard coating (3H)
kedalaman kaca0.50+0.50 mm
ketransmisian5.6% (Typ.)(with Polarizer)
nisbah kontras3000:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
antara muka isyaratLVDS (2 ch, 8/10-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T500HVN01.0 AUO 50 1920×1080
T500HVN02.2 CELL AUO 50 1920×1080
T500HVN04.1 CELL AUO 50 1920×1080
T500HVN04.5 CELL AUO 50 1920×1080
T500HVN04.6 AUO 50 1920×1080
T500HVN05.0 CELL AUO 50 1920×1080
T500HVN07.3 CELL AUO 50 1920×1080
T500HVN07.5 CELL AUO 50 1920×1080
V500DK1-KS1 Innolux 50 3840×2160
V500DK1-KS5 Innolux 50 3840×2160
