V500DJ5-QS1 Rev.R2

V500DJ5-QS1 Rev.R2
V500DJ5-QS1 Rev.R2
V500DJ5-QS1 Rev.R2 thumb V500DJ5-QS1 Rev.R2 thumb
Jenama
Innolux
Saiz
50
Permohonan
TV Sets
Resolusi
3840×2160
Komposisi
CELL ,   a-Si TFT-LC
Kecerahan
CR
5000:1
Warna
1.07B
Lampu latar
No
Antara muka
V-by-One
In Stock
12202
Spesifikasi

Nombor Bahagian V500DJ5-QS1 Rev.R2
JenamaInnolux
Saiz50
PermohonanTV Sets
Resolusi3840×2160
KomposisiCELL ,   a-Si TFT-LC
Kecerahan
CR5000:1
Warna1.07B
Lampu latarNo
Antara mukaV-by-One
pengilangInnolux
nama modelV500DJ5-QS1 Rev.R2
saiz skrin50 inch
jenis skrinCELL ,   a-Si TFT-LCD
nombor piksel3840(RGB)×2160   (UHD)  89PPI
susunanRGB Vertical Stripe
kawasan aktif (mm)1095.84 × 616.41 (H×V)
garis besar (mm)1106.84 × 628.01 × 1.32 (H×V×D)
kawasan bezel (mm)-
rawatanAntiglare (Haze 1%), Hard coating (3H)
kecerahan0 cd/m²
nisbah kontras5000 : 1 (Typ.) (TM)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)
tindak balas9.5 (Typ.)(G to G) ms
pandangan yang baik diSymmetry
mod kerjaSuper MVA, Normally Black, Transmissive
ketebalan kaca0.50+0.50 mm
ketransmisian4.8% (Typ.)(with Polarizer)
kedalaman warna1.07B   69% NTSC
lampu latarNo B/L
jisim2.01/2.10Kgs (Typ./Max.)
digunakan untukTV Sets
kadar segar semula60Hz
skrin sentuhWithout
senarai ic pemanduBuilt-in COF 12 source + 12 gate chips
jenis isyaratV-by-One 8 lane , 51 pins Connector
bekalan voltan12.0V (Typ.)
maks. penilaianStorage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C
Model Keluarga
PM50H3000 COC 50 1365×768
PM50H4000 COC 50 1365×768
T500DB01 V0 AUO 50 2560×1080
T500HVN04.1 CELL AUO 50 1920×1080
T500HVN04.5 CELL AUO 50 1920×1080
T500HVN04.6 AUO 50 1920×1080
T500QVN01.1 CELL AUO 50 3840×2160
V500DJ4-QS1 Innolux 50 3840×2160
V500HJ1-ME1 Innolux 50 1920×1080
V500HK1-LS6 Rev.C7 Innolux 50 1920×1080
