Innolux V201B1-L01 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com

V201B1-L01


Jenama
Innolux
Saiz
20.1
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1000:1
Warna
16.2M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
142
Spesifikasi

Nombor Bahagian V201B1-L01
JenamaInnolux
Saiz20.1
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1000:1
Warna16.2M
Lampu latarCCFL
Antara mukaLVDS
jenama panelCMO
model panelV201B1-L01
jenis panel a-Si TFT-LCD , LCM
saiz panel20.1 inch
resolusi1366(RGB)×768 , WXGA
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif444.633×249.984 mm
garis besar473.3×276.7×44.75 mm
permukaanAntiglare (Haze 40%), Hard coating (3H), Reflection 2.0% (Max.)
kecerahan500 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.2M (6-bit + FRC), CIE193175%
masa tindak balas8 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan60Hz
jenis lampu5 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanLCTV
