| Nombor Bahagian | TX20D33VM2BAC |
| Jenama | KOE |
| Saiz | 8.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | CMOS |
| pengilang | KOE |
| saiz skrin | 8.0 inch |
| nombor piksel | 800(RGB)×480 (WVGA) 116PPI |
| kawasan aktif (mm) | 174 × 104.4 (H×V) |
| kawasan bezel (mm) | 187.0 × 108.4 (H×V) |
| kecerahan | - |
| sudut pandangan | 80/80/60/80 (Typ.)(CR≥10) |
| pandangan yang baik di | 6 o'clock |
| kedalaman warna | 262K |
| jisim | 160g |
| kadar segar semula | 60Hz |
| jenis isyarat | CMOS (1 ch, 6-bit) , 40 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| nama model | TX20D33VM2BAC |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 189 × 120 × 8 (H×V×D) |
| rawatan | - |
| nisbah kontras | 600 : 1 (Typ.) (TM) |
| tindak balas | 20 (Typ.)(Tr+Td) ms |
| mod kerja | TN, Normally White, Transmissive |
| lampu latar | WLED , 50K hours , No Driver |
| digunakan untuk | Industrial |
| skrin sentuh | Without |
