| Nombor Bahagian | LD080WX2-SMN1 |
| Jenama | LG Display |
| Saiz | 8.0 |
| Permohonan | PAD |
| Resolusi | 800×1280 |
| Komposisi | LCM |
| Kecerahan | 330 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | LG Display |
| model panel | LD080WX2-SMN1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.0 inch |
| resolusi | 800(RGB)×1280 , WXGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 107.64×172.224 mm |
| garis besar | 114.6×184.55×4.25 mm |
| permukaan | Hard coating |
| kecerahan | 330 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193150% |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S3PWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 34 pins |
| voltan masukan | 1.8/5.2/-5.2V (Typ.)(VDDI/AVDD/AVEE) |
| permohonan | PAD |
