| Nombor Bahagian | TX20D208VM0BAA |
| Jenama | HITACHI |
| Saiz | 8.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | HITACHI |
| model panel | TX20D208VM0BAA |
| saiz panel | 8.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 116PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 174(W)×104.4(H) mm |
| pembukaan bezel | 177.4(W)×107.8(H) mm |
| saiz garis besar | 190.8(W)×120.5(H) ×16.2(D) mm |
| permukaan | - |
| kecerahan | 1200 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 30 (Max.)(Tr+Td) |
| warna paparan | 16.7M 70% NTSC |
| jenis lampu | WLED , 100K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 275g (Typ.) |
| permohonan | Industrial Outdoor High Brightness Automotive Display |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
