| Nombor Bahagian | TX20D202VM2BAA |
| Jenama | HITACHI |
| Saiz | 8.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | , |
| Antara muka | LVDS |
| pengilang | HITACHI |
| nama model | TX20D202VM2BAA |
| saiz skrin | 8.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 116PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 174 × 104.4 (H×V) |
| garis besar (mm) | - |
| kawasan bezel (mm) | - |
| rawatan | Antiglare |
| kecerahan | - |
| nisbah kontras | 600 : 1 (Typ.) (TM) |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | , No Driver |
| jisim | - |
| digunakan untuk | Industrial |
| jenis isyarat | LVDS |
