| Nombor Bahagian | EK08009-70235 |
| Jenama | Other |
| Saiz | 8.0 |
| Permohonan | DPF |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | No Brand |
| model panel | EK08009-70235 4 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.0 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 162×121.5 mm |
| garis besar | 183×141 mm |
| permukaan | Antiglare |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193150% |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S11PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit), 50 pins |
| voltan masukan | 3.3/10.4V (Typ.)(VCC/AVDD) |
| rohs: | |
| permohonan | DPF |
