KOE TX18D211VM0BAA lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com

TX18D211VM0BAA


Jenama
KOE
Saiz
7.0
Permohonan
Industrial Outdoor H
Resolusi
800×480
Komposisi
LTPS TFT-LCD, LCM
Kecerahan
CR
1000:1
Warna
262K
Lampu latar
WLED
Antara muka
LVDS
In Stock
11061
Spesifikasi

Nombor Bahagian TX18D211VM0BAA
JenamaKOE
Saiz7.0
PermohonanIndustrial Outdoor H
Resolusi800×480
KomposisiLTPS TFT-LCD, LCM
Kecerahan
CR1000:1
Warna262K
Lampu latarWLED
Antara mukaLVDS
jenama panelKOE
model panelTX18D211VM0BAA
saiz panel7.0"
jenis panelLTPS TFT-LCD, LCM
resolusi800(RGB)×480, WVGA, 133PPI
format pikselRGB Vertical Stripe
kawasan paparan152.4(W)×91.44(H) mm
pembukaan bezel156.2(W)×94.5(H) mm
saiz garis besar167.7(W)×109.5(H) ×20.3(D) mm
permukaan-
kecerahan1200 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.) (TM)
sudut pandangan85/85/85/85 (Typ.)(CR≥10)
mod paparanIPS, Normally Black, Transmissive
pandangan terbaik padaSymmetry
masa tindak balas30 (Typ.)(Tr+Td)
warna paparan262K   73% NTSC
jenis lampuWLED , 50K hours , With LED Driver
kekerapan60Hz
skrin sentuhWithout
berat panel219g (Typ.)
permohonanIndustrial Outdoor High Brightness Automotive Display
antara muka isyaratLVDS (1 ch, 6-bit) , 20 pins Connector
voltan masukan3.3V (Typ.)
persekitaranOperating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²)
