| Nombor Bahagian | TX11D201VM0BAA |
| Jenama | KOE |
| Saiz | 4.2 |
| Permohonan | Automotive Display |
| Resolusi | 480×272 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | KOE |
| model | TX11D201VM0BAA |
| saiz pepenjuru | 4.2 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 480(RGB)×272 [WQVGA] 131PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 92.88(H)×52.632(V) mm |
| garis besar malap. | 102.5(H)×69(V) ×15.5(D) mm |
| kawasan bezel | 95.28(H)×55.07(V) mm |
| rawatan | Antiglare, Hard coating (2H) |
| kecerahan | 750 cd/m² (Typ.) |
| nisbah kontras | 1500:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M 65% NTSC |
| sumber cahaya | WLED [6S1P] , 50K hours , With LED Driver |
| berat badan | 97.0g (Typ.) |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel RGB (1 ch, 8-bit) , 68 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ042T5DZ11 | SHARP | 4.2 | 480×272 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
