| Nombor Bahagian | TV101WXM-NU5 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 7S4P |
| Antara muka | |
| pengilang | BOE |
| saiz skrin | 10.1 inch |
| nombor piksel | 800(RGB)×1280 (WXGA) 150PPI |
| kawasan aktif (mm) | 135.36 × 216.576 (H×V) |
| kawasan bezel (mm) | 137.76 × 220.076 (H×V) |
| kecerahan | 400 (Typ.)(cd/m²) |
| sudut pandangan | 85/85/85/85 (Min.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 60% NTSC |
| jisim | 135g (Max.) |
| kadar segar semula | 60Hz |
| nama model | TV101WXM-NU5 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 142.32 × 228.2 × 4.3 (H×V×D) |
| rawatan | - |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| mod kerja | ADS, Normally Black, Transmissive |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| lampu latar | 7S4P WLED , No Driver |
| digunakan untuk | Pad & Tablet |
| skrin sentuh | Without |
