| Nombor Bahagian | TV097FMM-LB0-1SP0 |
| Jenama | BOE |
| Saiz | 9.7 |
| Permohonan | Pad & Tablet |
| Resolusi | 1280×1752 |
| Komposisi | a-Si TFT-LCD , Assem |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | BOE |
| saiz pepenjuru | 9.7 inch |
| format piksel | 1280(RGB)×1752 223PPI |
| kawasan aktif | 145.344(H)×198.94(V) mm |
| kawasan bezel | - |
| kecerahan | 320 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 70% NTSC |
| berat badan | 115g (Max.) |
| kadar bingkai | 60Hz |
| jenis antara muka | MIPI (4 data lanes) , 45 pins Connector |
| bekalan kuasa | 1.8/5.7/-5.7V (Typ.)(VDD/AVDD/AVEE) |
| persekitaran | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | TV097FMM-LB0-1SP0 |
| menaip | a-Si TFT-LCD , Assembly |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 150.344(H)×208.29(V) mm |
| rawatan | Clear, Hard coating |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| masa tindak balas | 35 (Max.)(G to G) |
| mod operasi | - |
| sumber cahaya | WLED [9S4P] , 15K hours , W/O Driver |
| direka untuk | Pad & Tablet |
| panel sentuh | In-Cell Touch |
