| Nombor Bahagian | TM150TDSG80 |
| Jenama | TIANMA |
| Saiz | 15.0 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | TIANMA |
| model panel | TM150TDSG80 |
| saiz panel | 15.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 85PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 304.128(W)×228.096(H) mm |
| pembukaan bezel | 307.4(W)×231.3(H) mm |
| saiz garis besar | 326.5(W)×253.5(H) ×10(D) mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 12 o'clock |
| masa tindak balas | 8 (Typ.)(Tr+Td) |
| warna paparan | 262K/16.7M 60% NTSC |
| jenis lampu | WLED , 30K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | TBD |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
| TM150SP-02L01 | SANYO | 15.0 | 1400×1050 |
| TM150TCS02 | Tianma | 15.0 | 1024×768 |
| TM150TDS50 | Tianma | 15.0 | 1024×768 |
| TM150TDSG52 | Tianma | 15.0 | 1024×768 |
| TM150TDSG53 | Tianma | 15.0 | 1024×768 |
| TM150TDSG70 | Tianma | 15.0 | 1024×768 |
| TM150XG-02L11 | SANYO | 15.0 | 1024×768 |
| TM150XG-22L01A | SANYO | 15.0 | 1024×768 |
| TM150XG-26L06A | SANYO | 15.0 | 1024×768 |
| TM150XG-A02-01 | SANYO | 15.0 | 1024×768 |
