| Nombor Bahagian | TM150TDSG59 |
| Jenama | AVIC |
| Saiz | 15.0 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AVIC |
| saiz panel | 15.0" |
| resolusi | 1024(RGB)×768, XGA, 85PPI |
| kawasan paparan | 304.128(W)×228.096(H) mm |
| kecerahan | - |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 262K/16.7M 60% NTSC |
| kekerapan | 60Hz |
| berat panel | - |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
| model panel | TM150TDSG59 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| nisbah kontras | 600:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 3/5 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 30K hours |
| skrin sentuh | Without |
| permohonan | Industrial |
