| Nombor Bahagian | TM123XDHP90 |
| Jenama | TIANMA |
| Saiz | 12.3 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 10S4P |
| Antara muka | LVDS |
| jenama panel | TIANMA |
| model panel | TM123XDHP90 |
| saiz panel | 12.3" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×720, 166PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 292.32(W)×109.62(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 311(W)×130(H) ×15.7(D) mm |
| permukaan | Antiglare (Haze 28%) |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | - |
| mod paparan | SFT, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| warna paparan | 16.7M 98% sRGB |
| jenis lampu | 10S4P WLED , 10K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 490g (Typ.) |
| permohonan | Industrial Outdoor High Brightness Automotive Display |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 50 pins FPC |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
