| Nombor Bahagian | TM104TDGP10 |
| Jenama | TIANMA |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 262K/16.7M |
| Lampu latar | 8S4P |
| Antara muka | LVDS |
| jenama panel | TIANMA |
| saiz panel | 10.4" |
| resolusi | 1024(RGB)×768, XGA, 123PPI |
| kawasan paparan | 210.432(W)×157.824(H) mm |
| saiz garis besar | 230(W)×175.8(H) ×9.06(D) mm |
| kecerahan | 450 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 262K/16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat panel | 430g (Typ.) |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | TM104TDGP10 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 213.43(W)×160.82(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| mod paparan | SFT, Normally Black, Transmissive |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| jenis lampu | 8S4P WLED , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
