| Nombor Bahagian | TM101JDHG38 |
| Jenama | TIANMA |
| Saiz | 10.1 |
| Permohonan | Industrial Medical I |
| Resolusi | 1280×800 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 6S5P |
| Antara muka | LVDS |
| pengilang | TIANMA |
| nama model | TM101JDHG38 |
| saiz skrin | 10.1 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1280(RGB)×800 (WXGA) 149PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 216.96 × 135.6 (H×V) |
| garis besar (mm) | 231.22 × 150.6 × 6.6 (H×V×D) |
| kawasan bezel (mm) | 219.96 × 138.6 (H×V) |
| rawatan | Hard coating |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | SFT, Normally Black, Transmissive |
| kedalaman warna | 262K/16.7M 50% NTSC |
| lampu latar | 6S5P WLED , 30K hours , With LED Driver |
| jisim | 276g |
| digunakan untuk | Industrial Medical Imaging VOIP Phone |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (1 ch, 6/8-bit) , Connector 40 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
