| Nombor Bahagian | TM070RDHG34 |
| Jenama | TIANMA |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 3S8P |
| Antara muka | |
| pengilang | TIANMA |
| nama model | TM070RDHG34 |
| saiz skrin | 7.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 134PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 154.08 × 85.92 (H×V) |
| garis besar (mm) | 164.9 × 100 × 6 (H×V×D) |
| kawasan bezel (mm) | 157.08 × 89.39 (H×V) |
| rawatan | Antiglare |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 70/70/60/70 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | 6 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | 3S8P WLED , 50K hours , No Driver |
| jisim | TBD |
| digunakan untuk | Industrial Outdoor High Brightness Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
