| Nombor Bahagian | TM070RDHG25 |
| Jenama | TIANMA |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 3S8P |
| Antara muka | |
| jenama panel | TIANMA |
| saiz panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 134PPI |
| kawasan paparan | 154.08(W)×85.92(H) mm |
| saiz garis besar | 164.9(W)×100(H) ×8.1(D) mm |
| kecerahan | 450 cd/m² (Typ.) |
| sudut pandangan | 80/80/60/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K 50% NTSC |
| kekerapan | 60Hz |
| berat badan | TBD |
| model panel | TM070RDHG25 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 157.08(W)×89.39(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 15 (Typ.)(Tr+Td) |
| jenis lampu | 3S8P WLED , 20K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
