| Nombor Bahagian | TM057KDH01-41 |
| Jenama | TIANMA |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 5S3P |
| Antara muka | Parallel |
| jenama panel | TIANMA |
| model panel | TM057KDH01-41 |
| saiz panel | 5.7" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 320(RGB)×240, QVGA, 70PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| pembukaan bezel | 118.2(W)×89.4(H) mm |
| saiz garis besar | 144(W)×104.6(H) ×12.8(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| sudut pandangan | 70/70/70/60 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 12 o'clock |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| warna paparan | 262K 50% NTSC |
| jenis lampu | 5S3P WLED , 50K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 160g (Typ.) |
| permohonan | Industrial |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| ET0570B0DHU | EDT | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| KCS057QV1BR-G21 | Kyocera | 5.7 | 320×240 |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057KDH05 | Tianma | 5.7 | 320×240 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
