| Nombor Bahagian | TM050RDH03-00 |
| Jenama | TIANMA |
| Saiz | 5.0 |
| Permohonan | Industrial Portable |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 7S2P |
| Antara muka | Parallel |
| jenama panel | TIANMA |
| model panel | TM050RDH03-00 0 Compatible |
| saiz panel | 5.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 188PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 108(W)×64.8(H) mm |
| pembukaan bezel | 111.1(W)×67.9(H) mm |
| saiz garis besar | 120.7(W)×75.8(H) ×3.1(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) (TM) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 12 o'clock |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| warna paparan | 16.7M 50% NTSC |
| jenis lampu | 7S2P WLED , 20K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | TBD |
| permohonan | Industrial Portable Navigation MID UMPC MP3 PMP |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| A050BTS30R0 | Aptus | 5.0 | 480×480 |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AT050TN33 V.1 | Innolux | 5.0 | 480×272 |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
