| Nombor Bahagian | TM028HDZ58 |
| Jenama | TIANMA |
| Saiz | 2.8 |
| Permohonan | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 65K/262K |
| Lampu latar | 1S4P |
| Antara muka | Parallel |
| pengilang | TIANMA |
| nama model | TM028HDZ58 |
| saiz skrin | 2.8 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 240(RGB)×320 (QVGA) 141PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 43.2 × 57.6 (H×V) |
| garis besar (mm) | - |
| kecerahan | - |
| nisbah kontras | 500 : 1 (Typ.) (TM) |
| sudut pandangan | 60/60/60/50 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | 6 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 65K/262K 55% NTSC |
| lampu latar | 1S4P WLED , No Driver |
| jisim | - |
| digunakan untuk | Mobile Phone |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | Parallel RGB (1 ch, 6-bit) + SPI |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
