| Nombor Bahagian | H572DAN01.2 |
| Jenama | AUO |
| Saiz | 5.7 |
| Permohonan | MPH |
| Resolusi | 1080×1920 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | MIPI |
| jenama panel | AUO |
| model panel | H572DAN01.2 |
| jenis panel | LTPS TFT-LCD , CELL |
| saiz panel | 5.7 inch |
| resolusi | 1080(RGB)×1920 , FHD |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 71.28×126.72 mm |
| garis besar | 73.68×133.27 mm |
| permukaan | Hard coating |
| kedalaman kaca | 0.15+0.15 mm |
| ketransmisian | 4.8% (Typ.)(with Polarizer) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 20/15 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| ic pemandu | COG Built-in R63311 |
| permohonan | MPH |
