| Nombor Bahagian | TD025THED2 |
| Jenama | TPO |
| Saiz | 2.5 |
| Permohonan | MPH |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | TPO |
| model panel | TD025THED2 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 2.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 49.92×37.44 mm |
| garis besar | 56.4×49.12×2.5 mm |
| permukaan | |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193170% |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 55/55/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| voltan masukan | 1.8/2.8V (Typ.)(VDDI/VDD) |
| permohonan | MPH |
