| Nombor Bahagian | TCG121XGLPBPNN-AN40-S |
| Jenama | Kyocera |
| Saiz | 12.1 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | Kyocera |
| model panel | TCG121XGLPBPNN-AN40-S |
| saiz panel | 12.1" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 105PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 245.76(W)×184.32(H) mm |
| pembukaan bezel | 249.0(W)×187.5(H) mm |
| saiz garis besar | 260.5(W)×203(H) ×10.9(D) mm |
| permukaan | Antiglare |
| kecerahan | 780 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | AWV, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 18/12 (Typ.)(Tr/Td) |
| warna paparan | 262K/16.2M 51% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 555g |
| permohonan | Industrial Outdoor High Brightness |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
