| Nombor Bahagian | TCG101WXLPAANN-AN20-S |
| Jenama | Kyocera |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | Kyocera |
| model panel | TCG101WXLPAANN-AN20-S |
| saiz panel | 10.1" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(RGB)×800, WXGA, 149PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 216.96(W)×135.6(H) mm |
| pembukaan bezel | 219.96(W)×138.6(H) mm |
| saiz garis besar | 236(W)×156.8(H) ×9.9(D) mm |
| permukaan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | 8/22 (Typ.)(Tr/Td) |
| warna paparan | 16.2M 50% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 500g (Typ.) |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| EJ101IA-01G | Innolux | 10.1 | 1280×800 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTN101NT06-W01 | Samsung | 10.1 | 1024×600 |
| M101NWT2 R3 | IVO | 10.1 | 1024×600 |
