AUO T500HVN01.0 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T500HVN01.0

T500HVN01.0
T500HVN01.0
T500HVN01.0 thumb T500HVN01.0 thumb
Jenama
AUO
Saiz
50
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
3000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
16739
Spesifikasi

Nombor Bahagian T500HVN01.0
JenamaAUO
Saiz50
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR3000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelT500HVN01.0
jenis panel a-Si TFT-LCD , LCM
saiz panel50 inch
resolusi1920(RGB)×1080 , FHD
mod paparanAMVA3, Normally Black, Transmissive
kawasan aktif1095.84×616.41 mm
garis besar1121.6×644.3×26.2 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kecerahan350 cd/m² (Typ.)
nisbah kontras3000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8/10-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T500HVD01.0 AUO 50 1920×1080
T500HVN01.0 AUO 50 1920×1080
T500HVN02.2 CELL AUO 50 1920×1080
T500HVN04.1 CELL AUO 50 1920×1080
T500HVN04.5 CELL AUO 50 1920×1080
T500HVN04.6 AUO 50 1920×1080
T500HVN05.0 CELL AUO 50 1920×1080
T500HVN07.3 CELL AUO 50 1920×1080
T500HVN07.5 CELL AUO 50 1920×1080
