AUO T315XW03 VF lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T315XW03 VF

T315XW03 VF
T315XW03 VF
T315XW03 VF
T315XW03 VF thumb T315XW03 VF thumb T315XW03 VF thumb
Jenama
AUO
Saiz
31.5
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
400
CR
3000:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
17
Spesifikasi

Nombor Bahagian T315XW03 VF
JenamaAUO
Saiz31.5
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan400
CR3000:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelAUO
model panelT315XW03 VF
jenis panel a-Si TFT-LCD , LCM
saiz panel31.5 inch
resolusi1366×768(RGB) , WXGA
mod paparanVA, Normally Black, Transmissive
kawasan aktif697.685×392.256 mm
garis besar760×450×47.9 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kecerahan400 cd/m² (Typ.)
nisbah kontras3000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T315XW02 VK AUO 31.5 1366×768
T315XW02 VT AUO 31.5 1366×768
T315XW02 VV AUO 31.5 1366×768
T315XW03 VD AUO 31.5 1366×768
T315XW03 VF CELL AUO 31.5 1366×768
T315XW04 V0 AUO 31.5 1366×768
T315XW06 V0 AUO 31.5 1366×768
T315XW06 V3 AUO 31.5 1366×768
T315XW06 V5 AUO 31.5 1366×768
T315XW07 V0 AUO 31.5 1366×768
