| Nombor Bahagian | T315XW02 VL |
| Jenama | AUO |
| Saiz | 31.5 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 2500:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | T315XW02 VL |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 31.5 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | AMVA, Normally Black, Transmissive |
| kawasan aktif | 697.685×392.256 mm |
| garis besar | 760×450 mm |
| permukaan | Antiglare (Haze 11%), Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 2500:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 6.5 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | CCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
| T315XW02 VC | AUO | 31.5 | 1366×768 |
| T315XW02 VF | AUO | 31.5 | 1366×768 |
| T315XW02 VM | AUO | 31.5 | 1366×768 |
| T315XW02 VV | AUO | 31.5 | 1366×768 |
| T315XW03 VD | AUO | 31.5 | 1366×768 |
| T315XW03 VE | AUO | 31.5 | 1366×768 |
| T315XW03 VF CELL | AUO | 31.5 | 1366×768 |
| T315XW04 V0 | AUO | 31.5 | 1366×768 |
| T315XW06 V0 | AUO | 31.5 | 1366×768 |
| T315XW06 V5 | AUO | 31.5 | 1366×768 |
| LC320EUD-SCA1 | LG Display | 31.5 | 1920×1080 |
| LC320EXJ-SEE2 | LG Display | 31.5 | 1366×768 |
| LC520WU1-SLB2 | LG Display | 52 | 1920×1080 |
| LC550EUE-SEF1 | LG Display | 55 | 1920×1080 |
| LK315T3LA61 | SHARP | 31.5 | 1366×768 |
| LTA320W1-L02 | Samsung | 31.5 | 1280×768 |
| T315HW04 V9 | AUO | 31.5 | 1920×1080 |
| T390XVN01.0 CELL | AUO | 39 | 1366×768 |
| V420H1-LH4 | Innolux | 42 | 1920×1080 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
