AUO T260XW02 VK lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T260XW02 VK

T260XW02 VK
T260XW02 VK
T260XW02 VK
T260XW02 VK thumb T260XW02 VK thumb T260XW02 VK thumb
Jenama
AUO
Saiz
26.0
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1500:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
1
Spesifikasi

Nombor Bahagian T260XW02 VK
JenamaAUO
Saiz26.0
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1500:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelAUO
model panelT260XW02 VK
jenis panel a-Si TFT-LCD , LCM
saiz panel26.0 inch
resolusi1366(RGB)×768 , WXGA
mod paparanVA, Normally Black, Transmissive
kawasan aktif575.769×323.712 mm
garis besar626×373 mm
permukaanAntiglare, Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras1500:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas8 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu6 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 8-bit), 41 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T260XW02 V0 AUO 26.0 1366×768
T260XW02 V9 AUO 26.0 1366×768
T260XW02 VP AUO 26.0 1366×768
T260XW02 VS AUO 26.0 1366×768
T260XW03 V0 AUO 26.0 1366×768
T260XW03 V2 AUO 26.0 1366×768
T260XW03 V3 AUO 26.0 1366×768
T260XW04 V2 AUO 26.0 1366×768
T260XW04 V5 AUO 26.0 1366×768
T260XW06 V5 AUO 26.0 1366×768
